ML307C-DL-CN Wireless Communication Module LTE Cat.1 Wireless Internet Module

ML307C-DL-CN Wireless Communication Module LTE Cat.1 Wireless Internet Module​

Product Description Of ML307C-DL-CN

ML307C-DL-CN is an LTE Cat.1 wireless internet module widely used in various consumer products (Cat.1 Dougle, POs, IPC, POC, locators, etc.) and industrial products (DUT, sensors). ML307C-DL-CN Adopting LCC+LGA packaging; The size is 17.7mm x 15.8mm x 2.2mm.

Specification Of ML307C-DL-CN

Network standard: LTE-FDD, LTE-TDD
Supply Voltage:
- Range:3.4V~4.5V
- Typical value:3.8V
Transmission power: 23dBm± 2dB
Storage temperature:-45℃ ~ 90℃
Working voltage range: DC 3.4V ~ 4.5V(typical value 3.8V)
Size: 17.7mm x 15.8mm x 2.2mm

Features Of ML307C-DL-CN

Theoretical speed
LTE-FDD: Maximum downlink rate of 10Mbps, maximum uplink rate of 5Mbps
LTE-TDD: Maximum downlink speed of 9.010Mbps, maximum uplink speed of 3.096Mbps
Working frequency band
LTE-FDD Band 1/Band 3/Band 5/Band 8
LTE-TDD Band 34/Band 38/Band 39/Band 40/Band 41
Transmission power: 23dBm± 2dB
Temperature and Humidity
Normal operating temperature: -30℃ ~ 75 °C
Extended working temperature:-40 °C ~ 85 °C
Storage temperature:-45℃ ~ 90℃
Working voltage range: DC 3.4V ~ 4.5V(typical value 3.8V)
