Détails sur le produit:
|
Numéro de pièce: | LPC824M201JDH20 | Cœur: | BRAS Cortex M0+ |
---|---|---|---|
Taille de la mémoire du programme: | 32 Ko | Fréquence d'horloge maximale: | 30 mégahertz |
Taille de RAM de données: | 8 KBS | Nombre d'E / OS: | Entrée-sortie 16 |
LPC824M201JDH20 Microcontroller MCU ARM Cortex M0+ Microcontroller IC 30MHz 32Bit MCU
Product Description Of LPC824M201JDH20
LPC824M201JDH20 is an ARM Cortex-M0+ based, low-cost 32-bit MCU family operating at CPU frequencies of up to 30 MHz. LPC824M201JDH20 support up to 32 KB of flash memory and 8 KB of SRAM. The peripheral complement of the LPC82x includes a CRC engine, four I2C-bus interfaces, up to three USARTs, up to two SPI interfaces, one multi-rate timer, self-wake-up timer, and state-configurable timer with PWM function (SCTimer/PWM), a DMA, one 12-bit ADC and one analog comparator, function-configurable I/O ports through a switch matrix, an input pattern match engine, and up to 29 general-purpose I/O pins.
Specification Of LPC824M201JDH20
Core Processor
|
ARM® Cortex®-M0+
|
Core Size
|
32-Bit
|
Speed
|
30MHz
|
Connectivity
|
I2C, SPI, UART/USART
|
Peripherals
|
Brown-out Detect/Reset, DMA, POR, PWM, WDT
|
Number of I/O
|
16
|
Program Memory Size
|
32KB (32K x 8)
|
Program Memory Type
|
FLASH
|
RAM Size
|
8K x 8
|
Voltage - Supply (Vcc/Vdd)
|
1.8V ~ 3.6V
|
Data Converters
|
A/D 5x12b
|
Oscillator Type
|
Internal
|
Operating Temperature
|
-40°C ~ 105°C (TA)
|
Mounting Type
|
Surface Mount
|
Supplier Device Package
|
20-TSSOP
|
Package / Case
|
20-TSSOP (0.173", 4.40mm Width)
|
Features Of LPC824M201JDH20
System:
ARM Cortex-M0+ processor (revision r0p1), running at frequencies of up to 30 MHz with single-cycle multiplier and fast single-cycle I/O port.
ARM Cortex-M0+ built-in Nested Vectored Interrupt Controller (NVIC).
System tick timer.
AHB multilayer matrix.
Serial Wire Debug (SWD) with four break points and two watch points. JTAG boundary scan (BSDL) supported.
Memory:
Up to 32 KB on-chip flash programming memory with 64 Byte page write and erase. Code Read Protection (CRP) supported.
8 KB SRAM
Clock generation:
12 MHz internal RC oscillator trimmed to 1.5 % accuracy that can optionally be used as a system clock.
Crystal oscillator with an operating range of 1 MHz to 25 MHz.
Programmable watchdog oscillator with a frequency range of 9.4 kHz to 2.3 MHz
Unique device serial number for identification.
Single power supply (1.8 V to 3.6 V).
Operating temperature range -40 °C to +105 °C
Applications Of LPC824M201JDH20
Sensor gateways
Simple motor control
Industrial
Portables and wearables
Gaming controllers
Lighting
8/16-bit applications
Motor control
Consumer
Fire and security applications
Climate control
