LTC2485IDD Integrated Circuit Chip Analog To Digital Converters 24-Bit ADC Converters

LTC2485IDD Integrated Circuit Chip Analog To Digital Converters 24-Bit ADC Converters​

Product Description Of LTC2485IDD

LTC2485IDD combines a 24-bit plus sign No Latency ΔΣ™ analog-to-digital converter with patented Easy Drive technology and I2C digital interface. The patented sampling scheme eliminates dynamic input current errors and the shortcomings of on-chip buffering through automatic cancellation of differential input current. This allows large external source impedances and input signals, with rail-to-rail input range to be directly digitized while maintaining exceptional DC accuracy.

Specification Of LTC2485IDD

Features Of LTC2485IDD

Easy Drive™ Technology Enables Rail-to-Rail Inputs with Zero Differential Input Current
Directly Digitizes High Impedance Sensors with Full Accuracy
GND to VCC Input/Reference Common Mode Range
2-Wire I2C Interface
Programmable 50Hz, 60Hz or Simultaneous 50Hz/60Hz Rejection Mode
2ppm (0.25LSB) INL, No Missing Codes
1ppm Offset and 15ppm Full-Scale Error
Selectable 2x Speed Mode
No Latency: Digital Filter Settles in a Single Cycle
Single Supply 2.7V to 5.5V Operation
Internal Oscillator
Six Addresses Available and One Global Address for Synchronization
Available in a Tiny (3mm × 3mm) 10-Lead DFN Package

Applications Of LTC2485IDD

Direct Sensor Digitizer
Weight Scales
Direct Temperature Measurement
Strain Gauge Transducers
Instrumentation
Industrial Process Control
DVMs and Meters
