DS28E16Q Integrated Circuit Chip 1-Wire Secure SHA-3 Authenticator 6-TDFN Package

DS28E16Q Integrated Circuit Chip 1-Wire Secure SHA-3 Authenticator 6-TDFN Package

Product Description Of DS28E16Q
DS28E16Q secure authenticator combines FIPS202-compliant Secure Hash Algorithm (SHA-3) challenge and response authentication with secured EEPROM.

The device provides a core set of cryptographic tools derived from integrated blocks including a SHA-3 engine, 256 bits of secured user EEPROM, a decrement-only counter and a unique 64-bit ROM identification number (ROM ID). The unique ROM ID is used as a fundamental input parameter for cryptographic operations and serves as an electronic serial number within the application. The device communicates over the single-contact 1-Wire® bus. The communication follows the 1-Wire protocol with the ROM ID acting as node address in the case of a multidevice 1-Wire network.

Features Of DS28E16Q
Robust Countermeasures Protect Against Security Attacks
All Stored Data Cryptographically Protected from Discovery
Efficient Secure Hash Algorithm Authenticates Peripherals
FIPS 202-Compliant SHA-3 Algorithm for Challenge/Response Authentication
FIPS 198-Compliant Keyed-Hash Message Authentication Code (HMAC)
Supplemental Features Enable Easy Integration into End Applications
17-Bit One-Time Settable, Nonvolatile Decrement-Only Counter with Authenticated Read
Secure Storage for Secrets
256 Bits of Secure EEPROM for User Data
Unique and Unalterable Factory Programmed 64-Bit Identification Number (ROM ID)
Advanced 1-Wire Protocol Minimizes Interface to Single Contact
Full-Time Overdrive Communication Speed
Internal Parasite Power Capacitor
Operating Range: 1.71V–3.63V, -40°C to +85°C
WLP, TDFN-EP, and SFN Packages
±8kV HBM ESD Protection (typ)
3.5µA (typ) Input Load Current

Applications Of DS28E16Q
Accessory and Peripheral Secure Authentication
Battery Authentication and Charge Cycle Tracking
Medical Tools/Accessories Authentication and Calibration
